Autel MaxiIM IM508S Car Key Programmer immobilizer IMMO OBD2 OE-Level Diagnostic Tools Professional Automotive Scanner

The Price of China Warehouse is Tax Inclusive for European Buyers.

Autel MaxiIM IM508S 2024 Level-up of IM508 Key Fob Programming Tool w/ XP200, 11 OS, 4G+64G, 2.4&5G, 3000+ Bidirectional Active Tests, 40+ Resets All-System Diagnosis Same IMMO as IM508S PRO AutoAuth

The Reasons to buy IM508S

【XP200 Key Programmer for IMMO ECU Programming】

Specially designed to read Volkswagen vehicle key chip data, clone and generate exclusive keys, read/write on-board EEPROM data and read/write Freescale 9S12 MCUs. By working with diagnostic tool and PC that are both loaded with programmer software, the XP200 Key Programmer can read/write key chip data quickly and accurately for multi-brands.

【40+ Maintenance Services】

Autel IM508S supports full-systems special functions, like CKP Relearn, Injector Coding, Oil Reset, EPB, SAS, BMS, ABS bleed, Throttle Reset, Air Suspension, etc. and the coverage is 10%+ ahead of competitors and keep adding. Eg: To-yota widely supports 241 special functions like ID registration/ tire number registration, key-code registration, etc., and the coverage far exceeds that of competitors.

【Full Bidirectional Active Test】

2024 Workshop scanner IM508S is not only a IMMO tool, but also a powerful bidirectioinal scan tool. It can perform real active test that can send commands to vehicles’ ECU to drive the actuators to work and do actuators tests, like ABS bleed, window up/down, on/off, etc, helping technicians to quickly find out bad parts and locate issues.

【OE-Level Full System Diagnostics】

Autel IM508S professional workshop scanner can quickly access vehicles’ ECU to do full scans via included OBD2 cable & identify cars by AutoVIN or Manually Input. It performs OE-Level diagnosis, read ECU info, read/clear DTCs, view all sensors live data in 4 format(text/ wave graph/ histogram/ meter diagram), do active test, print the diagnosis data you need. Master cars situation with a few simple clicks!

【Autel Cloud Report Management】

This is an useful data sharing feature!! With it, you can upload diagnostic reports to Autel Cloud and share reports instantly with your customers through QR Code/ text message/ email easily, not limited via email anymore! They can view the reports anytime. Like other cloud space, it is a back garden for your diagnostic reports to help you enhance data centralization, share simply and quickly, reduce memory burden and improve work efficiency.

Supports Muti-Language

English, French, Spanish, Portuguese, German, Russian, Dutch, Japanese, Italian, Polish, and Korean etc.

■ Most Commonly Used Reset Services

Oil Rest Service: This function allows you to perform reset for the Engine Oil Life system, which calculates an optimal oil life change interval depending on the vehicle
driving conditions and climate. The Oil Life Reminder must be reset every time the oil is changed, so the system can calculate when the next oil change is required.

■ EPB Service

This function has a multitude of usages to maintain the electronic braking system safely and effectively. The applications include deactivating and activating the brake
control system, assisting with brake fluid control, opening and closing brake pads, and setting brakes after disc or pad replacement, etc.

■ SAS Service

Steering Angle Sensor Calibration permanently stores the current steering wheel position as the straight-ahead position in the steering angle sensor EEPROM. Therefore,
the front wheels and the steering wheel must be set exactly to the straight-ahead position before calibration.

■ TPMS Service

This function allows you to quickly look up the tire sensor IDs from the vehicle’s ECU, as well as to perform TPMS replacement and sensor test.

■ BMS Service

The BMS (Battery Management System) allows the scan tool to evaluate the battery charge state, monitor the close-circuit current, register the battery replacement
and activate the rest state of the vehicle.

■ DPF Service

This function is used to manage DPF regeneration, DPF component replacement teach-in and DPF teach-in after replacing the engine control unit.

■ OE-Level All Systems Diagnosis

Autel IM508 Car Scanner can perform OE-Level diagnosis on all car electronic systems like ABS, SRS, Engine, Transmission and etc and show live data of multiple sensors.
It is compatible with more than 80 American, Asian and European makes and models.

■ Auto Scan Technology

The Autel IM508 professional OBD2 scanner comes with Auto Scan function that performs a comprehensive scanning over all the ECUs in the vehicle to locate systems
faults and retrieve DTCs for efficient diagnosis.

■ Live Data & Review Freeze Frame Data

The IM508 car diagnostic scanner reads codes, show live data of multiple sensors in or graph or text, clears codes. The Review Data section allows you to playback the
recorded data frames of live data streams.

■ XP200 Key & Chip Programmer

XP200,and no vehicle connection is required.This application can access the key chip,read retrieve and write key information.

■Autel IM508 EEPROM Read/Write Supported Types

ATMEL
For AT24C01,AT24C02,AT24C04,AT24C08,AT24C16,AT24C32,AT24C64,AT24C128,AT24C256,AT24C512,AT24C1024,AT24C128_1.8
AT24C256_1.8,AT24C512_1.8,AT24C01A,AT25010,AT25020,AT25040,AT25080,AT25160,AT25320,AT25640,AT25128,AT25256
AT25512,AT25010_1.8,AT25020_1.8,AT25080_1.8,AT25320_1.8,AT25640_1.8,AT25128_1.8,AT25256_1.8,AT59C11,AT59C22
AT93C46A,AT59C13,AT93C46,AT93C46R,AT93C56,AT93C57,AT93C66,AT93C76,AT93C86

For CATALYST
CAT25C01,CAT25C02,CAT25C04,CAT25C08,CAT25C16,CAT25C32,CAT25C64,CAT25C128,CAT25C256

For FAIRCHILD
NM24C16U,NM24C16UT,NM24C17U,NM24C17UT,FM93CS46T

For MICROCHIP
85C72,85C82,85C92,25xx080,25xx160,25xx320,25xx640,25xx040_TSSOP,25xx320_TSSOP,25xx640_TSSOP,93C06,25xx040
93C46X,93C46A,93C46,93C46AX,93C46BX_93C46CX,93C56A,93C56,93C66A,93C66,93C76A,93C76,93C86A,93C86

For NXP
PCF8582C,PCF8594C,PCF8598C

For NATIONAL
NM93C13,NM93C14,NM93CS06,NM93C14TM8,NM93CS46,NM93CS56,NM93CS66

For OKI
MSM16911

For SONY
CXK1011,CXK1012,CXK1013

For Seiko
S_24S45,S_24H30,S_24H30_SOP8,S_24H45,S_24H45_SOP8,S_24S30

For ST
M24C01,M24C02,M24C04,M24C08,M24C16,M24C32,M24C64,ST24x01/ST25x01,ST24x02/ST25x02,ST24x04/ST25x04
ST24x08/ST25x08,ST24x16,ST25x16,AT25040_1.8,AT25160_1.8,M95010,M95020,M95160,M95040,M95080,M35080,M95320
M95640,M95256,M95128,M95512,M93C46,M93C56,M93C66,M93C76,M93C86,M93S46,M93S56,M93S66

TOSHIBA
TC89101,TC89102,TC89121,TC89122

For TMC
TMC93LC46,TMC93LC56,TMC93LC57,TMC93LC66,TMC93LC86

For XICOR
X5043,X5045,X25043,X25045,X24C44

For 9S12 Read/Write Supported Types
FREESCALE
MC9S12DG128

IM508 Don’t support the local vehicle

Australian car: Fordau, Holden
Malaysian car: Perodua,proton
Brazil, Latin America, South America: Fiat Brazil, Gm Brazil
Indian cars: Maruti Suzuki, Mahindra, Tat, India Datsun

If you need to add the following car software,please contact with us.

■ Autel MaxiIM IM508 Specifications

Operating System: AndroidTM 4.4.4
Processor: Cortex-A9 processor (1.6 GHz)
Memory: 32GB
Display: 7-inch LCD capacitive touchscreen with 1024×600 resolution
Connectivity: Mini USB 2.0
USB 2.0
Wi-Fi
Micro SD card (supports up to 32GB)
Sensors: Ambient light sensor for brightness auto changing
Audio Input / Output: Input: N/A
Output: buzzer
Power and Battery: 3.7 V/5000 mAh lithium-polymer battery, Charges via 5 VDC power supply
Tested Battery Life: Around 4.5 hours of continuous use
Battery Charging Input: 5 V/1.5 A
Power Consumption: 500 mA (LCD on with default brightness, Wi-Fi on) @3.7 V
Operating Temp. 0 to 50°C (32 to 122°F)
Storage Temp. -20 to 60°C (-4 to 140°F)
Operating Humidity: 5% – 95% non-condensing
Net Weight: 788 g (2.42 lb.)

■ Supported Automotive Protocols

ISO9141-2, ISO14230-2,ISO15765, K/L-Line, Flashing Code, SAE-J1850 VPW,SAE-J1850 PWM, ISO11898 (Highspeed, Middlespeed, Lowspeed and Singlewire CAN, fault-tolerant CAN), SAE J2610,GM UART,UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6

■ Autel MaxiIM IM508 Package List

1 X MaxiIM IM508S Tablet
1 X AAC001 – MED17 Cable
1 X KIA-20 Adaptor
1 X Mazda-17 Adaptor
1 X Carrying Case
1 X Quick guide
1 X Honda-3 Adaptor
1 X KIA-10 Adaptor
1 X XP200 Key Programmer
1 X USB External Power Adapter
1 X Main cable
1 X Mini USB Cable
